Capacity to Builtin HID module and HID compilable
Capacity to Builtin Voice module
Builtin Door Bell button
Illuminated Keypad Design for more visual operation
Weatherproof Design for outdoor use
High security Biometrics Device, the finger is the only key
RS485 and TCP/IP communication interface
User capacity: 16,000 Event log: 32,000
FingerprintUser capacity: 4,500~9000 (2~1 fingers for each user)
High recognition rate of fingerprint reader(FRR): <0,1%
Fingerprint Sensor can option the Optical Sensor(DO) or the Capasitive Sensor(MT)
Auth. Speed (1:N): 0.97Sec.(DO) / 0.65Sec.(MT)
Access modes: Finger only, Card and Finger, Card or PIN and Finger, Card and PIN and Finger
Builtin Watch Dog to prevent the halting
2 control modes: M4/ M8
63 autoopen zone settings and 16 sets of AutoOpen Zone editable
WG port provides antipassback function
One more Exit Switch, Door Contact and Door Output to wiegand
Builtin MultiOutput: Door Lock/ Alarm/ Arming/ Duress/ Security trigger signal
SOYAL software support for networking
Easily integrated with SOYAL or others access control system
Work attendance check: Push buttons to select Duty on/off work, Leave/Back and Overtime on/off Builtin Real Time Clock & AntiTamper functions
Flexible to integrate with other equipments
125kHz and 13.56MHz can be used simultaneously two channels
Patent for new type of Relay, avoid vibrating to MisTrigger
RS485 serial output for various application and lift control
Builtin 16 set of Alarm and 120 days of Holiday setting
Menu setting with LCD panel
Coordinating with softwares for further application on access control, time attendance, payroll, anddoor/sensor imagemonitor function
Autolock of the keypad for 30 seconds after continuous failed operation by 3 times
Including the input of door contact, offering the alarm system of both door opening too long and beingforced to open
Intelligent to shift for standalone or networking mode while system disconnected
Support Fire buttons to make sure the fire happening, all doors open
Supporting AR721_RB Relay Output module alternates traditional relay module, raise security, resist from stealing, and avoid wrong operation.
2 sets of AutoOpen Zone editable by standalone operation
